SILICA
JAWA
Silica Sand Jawa is commonly used material for building dst
Concrete Sand (Casting Sand): Silica Sand Jawa is classified as excellent concrete sand.
Coarse and Hard Texture: It has coarse and hard grains (ranging from slightly fine to coarse). This strength is crucial for producing sturdy and strong concrete mixtures.
Low Silt/Mud Content: Good sand for construction must have a low silt/mud content. Silica Sand Jawa generally has a low silt content, making it an ideal choice for cement mixtures.
Color: Generally yellowish-brown.
| Parameter | Unit | Results | Method |
|---|---|---|---|
| Iron Trioxide (Fe203) | % | 0.062 | PO/MIN-BT/01 (XRF) * |
| Calcium Oxide (Ca0) | % | 0.004 | PO/MIN-BT/01 (XRF) * |
| Magnesium Oxide (Mg0) | % | 0.01 | PO/MIN-BT/01 (XRF) * |
| Silicon Dioxide (Si02) | % | 98.99 | PO/MIN-BT/01 (XRF) * |
| Moisture Content (MC) | %, AR | 0.19 | PO/MIN-MP/15 (Gravimetric) ** |
| Particle size distribution | attached | GRAVIMETRI | |
| + 3.35 mm | % | 96.60 | GRAVIMETRI |
| + 1.00 mm | % | 3.22 | GRAVIMETRI |
| - 1.00 mm | % | 0.18 | GRAVIMETRI |
| Bulk density, loose | kg/L | 1.44 | ASTM C29-17 |
| Bulk density, densed | kg/L | 1.58 | ASTM C29-17 |
| Voids, uncompacted | % | 42.63 | ASTM C29-17 |
| Voids, compacted | % | 36.79 | ASTM C29-17 |
| Size fraction (mm) | Sample A (Total: 372.80 gr) | Sample B (Total: 500.00 gr) | ||
|---|---|---|---|---|
| Weight retained (%) | Cumulative pass (%) | Weight retained (%) | Cumulative pass (%) | |
| plus - 9.50 | 0.00 | 0.00 | 0.00 | 100.00 |
| 9.5 - 4.75 | 0.00 | 0.00 | 0.00 | 100.00 |
| 4.75 - 2.36 | 0.00 | 0.00 | 0.00 | 100.00 |
| 2.36 - 1.18 | 2.40 | 0.48 | 0.48 | 99.52 |
| 1.18 - 0.60 | 488.90 | 97.78 | 98.26 | 1.74 |
| 0.6 - 0.30 | 7.20 | 1.44 | 99.70 | 0.30 |
| 0.3 - 0.15 | 0.30 | 0.06 | 99.76 | 0.24 |
| 0.15 - 0.075 | 0.00 | 0.00 | 99.76 | 0.24 |
| pan | 1.20 | 0.24 | 100.00 | 0.00 |
| Total | 500.00 | 100.00 | 298.20 | -- |
